Core Specifications:
✔ Model: CB801 (3BSE042245R1)
✔ Protocol: PROFIBUS DP-V1 (IEC 61158 compliant)
✔ Data Rate: Up to 12 Mbps (auto-negotiation supported)
✔ Addressing: Configurable node address (1–126) via DIP switches
✔ Isolation: Galvanic isolation (500V AC) for noise immunity
Communication & Compatibility:
✔ Supported Networks:
PROFIBUS DP-V1 (cyclic data exchange, diagnostics)
Compatible with DP-V0 devices (backward compatibility)
✔ Integration:
Direct plug-in for ABB Panel 800 series (e.g., PU512, PU516)
GSD file provided for easy PLC configuration
Reliability & Protections:
✔ Operating Temperature: -20°C to +60°C (no derating within range)
✔ Humidity Tolerance: 5–95% RH (non-condensing)
✔ EMC Compliance: EN 61000-6-2 (immunity), EN 61000-6-4 (emissions)
✔ Surge Protection: ±1 kV (signal lines per IEC 61000-4-5)
Certifications & Safety:
✔ Standards: CE, UL, PROFIBUS ID (6GVD120xxxxx)
✔ Safety Isolation: Reinforced insulation per EN 61140
Mechanical & Installation:
✔ Form Factor: Compact module for Panel 800 rear slot
✔ Dimensions: 45mm × 100mm × 25mm (W×H×D)
✔ Connector: 9-pin D-sub (PROFIBUS) with screw terminals
✔ LED Indicators: Power, Tx/Rx, fault diagnostics
Key Applications:
✔ Factory Automation: PLC-to-HMI communication (e.g., Siemens, ABB AC500)
✔ Process Control: Integration with sensors/actuators
✔ Energy Management: Real-time data monitoring
Why Choose It?
✅ Plug-and-Play Simplicity – Pre-configured for Panel 800, minimal setup.
✅ PROFIBUS DP-V1 Advantages – Enhanced diagnostics and acyclic services.
✅ Industrial Robustness – Reliable in high-noise environments.
