Basic Specifications:
Key Features & Performance:
✔ High-Precision Input – 16-bit resolution ensures accurate measurement of analog signals
✔ Multi-Signal Support – Accepts 4-20mA, 0-10V, thermocouples (J/K/T types), RTDs
✔ Galvanic Isolation – Channel-to-channel isolation prevents signal interference
✔ High-Density Design – 16 channels in single-slot module for space efficiency
✔ Self-Diagnostics – Continuous monitoring with fault indication for quick troubleshooting
Technical Specifications:
Input Channels: 16 single-ended or 8 differential (configurable)
Sampling Rate: Up to 50 samples/second per channel
Accuracy: ±0.1% of full scale (typical)
Isolation: 500V channel-to-channel and channel-to-system
Operating Temperature: -25°C to +70°C
System Integration:
Compatibility: Designed for ABB's Advant Controller 800xA and AC 800M systems
Communication: Supports Profibus DP and other industrial protocols
Hot-Swappable: Allows replacement without system shutdown
Reliability & Compliance:
✔ Industrial Durability: Designed for harsh environments with high EMI resistance
✔ Certifications: Complies with IEC 61131, UL, CE, and ATEX standards
✔ ABB Quality: Manufactured under ABB's stringent quality control processes
