General Specifications:
Functional Features:
✅ 16-Bit High Resolution – Delivers ±0.05% accuracy for precise analog signal measurement.
✅ Isolated Inputs (Channel-to-Channel & Field-to-Logic) – Prevents ground loops and EMI noise (1500V AC isolation).
✅ Configurable Input Ranges:
Voltage: ±10V, ±5V, 0-10V, 0-5V.
Current: 0-20mA, 4-20mA.
✅ Programmable Filtering – Adjustable for noise reduction in critical applications.
✅ Diagnostics & LED Indicators – Detects open wire, overrange, and module faults.
Electrical & Environmental Specs:
Input Impedance: ≥1MΩ (voltage), 250Ω (current).
Update Rate: 10ms per channel (fast response for real-time control).
Operating Temperature: 0°C to +60°C (standard industrial range).
Certifications: UL, CE, c-UL (compliance with global standards).
Installation & Integration:
Mounting: 1771 I/O chassis (backplane-powered).
Termination: Removable screw terminal blocks.
Scalability: Supports up to 8 modules per chassis (depends on power budget).
Typical Applications:
Process Control (flow, pressure, temperature monitoring).
Factory Automation (motor control, load cell interfacing).
Energy Management (power distribution sensing).
