Key Features:
Compact 4-Slot Chassis – Houses up to 4 SCXI modules for signal conditioning (e.g., amplification, filtering, isolation).
High-Performance Backplane – Supports analog and digital triggering with low-noise signal paths for accurate measurements.
EMI/RFI Shielding – Reduces electromagnetic interference, critical for sensitive sensor signals (e.g., strain gauges, thermocouples).
Rugged Metal Enclosure – Industrial-grade design withstands vibrations and harsh environments (0–50°C operating temperature).
Easy Integration – Connects seamlessly to NI DAQ devices (e.g., PCI/PXI/USB) via SCXI cable kits for scalable systems.
LED Status Indicators – Visual feedback for power and module communication status.
Universal AC/DC Power – Supports 100–240V AC or 18–30V DC input for flexible deployment.
Applications:
✔ Sensor signal conditioning (strain, load, pressure)
✔ Test bench automation
✔ Industrial monitoring & control
✔ Research & lab measurements
✔ Noise-critical data acquisition
Compatibility & Status:
Works with SCXI Modules – Compatible with SCXI-1102, SCXI-1125, etc. (verify module specs).
Legacy Product – Discontinued but available refurbished; consider NI CompactDAQ for modern alternatives.
