GE Fanuc IC693MDL231E is a 16-point digital input module for Series 90-30 PLC systems, designed for industrial automation applications. It features 24V DC sinking inputs with optical isolation, ensuring reliable signal acquisition in noisy environments. With LED status indicators and high-density packaging, this module provides efficient integration into control systems while maintaining rugged durability for harsh industrial conditions.
Product Specifications
General Specifications:
Model: IC693MDL231E
Module Type: 16-Channel Digital Input
Compatibility: GE Fanuc Series 90-30 PLC
Input Type: 24V DC Sinking (Negative Logic)
Isolation: Optical (1500V AC)
Electrical Specifications:
Input Voltage Range: 15-30V DC (Nominal 24V)
Input Current: 6mA typical @ 24V DC
On-State Voltage: ≤ 5V DC (for "ON" recognition)
Off-State Voltage: ≥ 15V DC (for "OFF" recognition)
Response Time: ≤ 1ms (ON/OFF delay)
Protection & Diagnostics:
Overvoltage Protection: Yes (up to 30V continuous)
Reverse Polarity Protection: Yes
Short-Circuit Protection: Per-channel
LED Indicators: Per-point status (Green = ON, Off = OFF)
Module Health LED: Red (fault indication)
Mechanical & Environmental:
Connector Type: Removable screw terminal (included)
Mounting: DIN rail or panel mount
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Humidity: 5% to 95% (non-condensing)
Vibration Resistance: 5g @ 10-500Hz
Shock Resistance: 30g for 11ms
Certifications & Compliance:
UL Listed (UL 508)
CE Marked
RoHS Compliant
IEC 61131-2
